Installation

Follow these steps to successfully hang your Pixalot wall art or mirror.

Canvas Art & Mirrors

  1. On the back of your art/mirror you will see 2 brackets attached, and taped to the back you will find a pair of wall plugs & screws.
  2. Accurately measure the distance between the centre of the two brackets.
  3. Mark that distance on the wall where you want the wall art to hang, using a spirit level to ensure the 2 points are level.
  4. Drill the holes using a 6mm drill bit.
  5. Insert the wall plugs fully into the holes.
  6. Screw in the screws until the head is approx 5mm from the wall.
  7. Lift the wall art and slide the brackets over & down on to the screw heads.
  8. It should now sit securely in place, well done!
  9. If you find the art/mirror is not hanging level, or too high/low for your liking, the brackets can easily be repositioned using a star screwdriver, rather than drilling new holes.

NB: If the brackets do not slide effortlessly over the screw heads, DO NOT force/stretch the frame onto them. Over time the frame will bow & crack. You will need to reposition the brackets slightly, as per the previous point.

Framed Art (behind glass)

Follow the same instructions as above, but using the supplied T-screws and an 8mm drill bit. The T-screws should finish in a vertical position, thus:


 hanging screw position











If you are not confident doing the hanging we recommend using a professional hanging service such as:


(JHB) mrhangman.co.za / thehangman.co.za
(CT) picturehangingpros.co.za / picturehanging.co.za
